Cast Iron Electric Rotary Globe Valve with Actuator | FLE-Z20-SKG
Cast Iron Electric Rotary Globe Valve with Actuator | FLE-Z20-SKG
Lug type motorized round port knife gate valves provide tight shut-off and use an electric actuator for precise, reliable remote control. They are widely used in wastewater treatment, mining, chemical processing, and power generation applications.
Technical Specifications
| Electric Rotary Actuator | |
| FLE-Z20 Rotary Actuator with Globe Valve |
Ordinary ON-OFF Type |
|
Ordinary Adjustable Type |
|
|
Adjusting Switch Type |
|
| Intelligent Type
AC380V AC220V,Special Voltage Can be Customized |
|
| Power Supply | Conventional: Three-phase, AC380V (50 Hz) |
| Special: Three phase, AC660V, AC440V, and AC415V (50Hz and 60Hz) | |
| Special: Simplex, AC220V, AC110V ( 50Hz and 60Hz) | |
| Special: Direct, DC12V, DC24V, and DC48V | |
| Basic Error Limit | ≤1% |
| Protection Class | IP65、IP67, IP68 |
| Explosion-proof Grade | ExdII BT4、ExdII CT4 |
| Motor Working System | Standard Long-term Motor, F-class Insulation |
| Valve Body | |
| Size Range | DN50 – DN1000 |
| Pressure Rating | PN1.0Mpa~PN6Mpa |
| Temperature | -30 to 400℃ |
| Body Material | Cast Iron |
| Stem Material | Cast Iron |
| Sealing | PDEM: -10℃ ~120℃ / PTFE: -30℃ ~180℃ |
| Connection Type | Wafer, Flanged Type |
| Standard | GB/ANSI/JIS/DIN |
| Application Medium | Water, Gas, Oil, Powder, Steam, |
| Applications | Chemical, Water Treatment, Pulp & Paper, Mining, Boiler, etc |
| Boiler, etc | ||||||
| Actuator Model | Standard Time/Torque | Optional Time/Torque | Rotation Angle Range | Actuator Weight | Power Supply | Optional Control Circuit |
|---|---|---|---|---|---|---|
| FLE-105 | 25S/50Nm | 4S/20Nm 10S/30Nm |
0-90° Adjustable | 2.2kg | DC24V AC24V AC110V AC220V AC380V |
A type B type C type D type E type F type |
| FLE-110 | 25S/100Nm | 15S/50Nm | 5.1kg | |||
| FLE-116 | 25S/160Nm | 15S/80Nm | 5.1kg | |||
| FLE-120 | 25S/200Nm | 15S/100Nm | 7.5kg | |||
| FLE-140 | 25S/400Nm | 15S/200Nm | 7.5kg | |||
| FLE-160 | 25S/600Nm | 15S/300Nm | 8.1kg | |||
| FLE-1100 | 50S/1000Nm | 25S/500Nm | 12.7kg | |||
| FLE-1200 | 50S/2000Nm | 25S/1000Nm | 12.7kg | |||
| Type | ON/OFF, Regulating, Intelligent | |||||
| Insulation Resistance | 100MΩ/500VDC | |||||
| Dielectric Strength | 1500V AC 1min. | |||||
| Level of Protection | IP67 (IP68 optional) | |||||
| Installed Location | 360° Installation at any Angle | |||||
| Electrical Interface | 2-G1/2 Metal Fitting, the corresponding metal cable joints should be installed according to the selected cables | |||||
| Ambient temperature | -20°C to +60°C | |||||
| Optional Explosion Proof | Ex d II BT4 / CT4 / CT6 Gb | |||||
| Power-loss reset (fail-safe) function | Fail-open, Fail-closed or No-reset (factory-selectable) | |||||
| Optional functions | Overtorque protection, dehumidification heater, passive contact switch, operating handwheel | |||||
Product Benefits & Features
1. High Precision Control & Stable Operation
Digital integrated control system ensures high accuracy and stable performance
Torque measurement with ≤5% error rate and real-time dynamic monitoring
High-precision hybrid encoder provides Level 1 positioning accuracy
Reliable operation with over-torque and stalled rotor alarm protection
2. Compact Electric Actuator with Smart Functions
Mechatronic compact design with lightweight structure for easy installation
Supports ON-OFF, regulating, and intelligent control modes
Remote control capability reduces manual operation and labor cost
Compatible with industrial automation systems (PLC / DCS integration)
3. Durable Materials & Strong Industrial Adaptability
Cast iron valve body with robust mechanical strength
PTFE sealing ensures corrosion resistance and long-term stability
Suitable for water, gas, oil, steam, and general industrial media
Designed for high reliability in continuous operation environments
4. Easy Installation & Low Maintenance Design
ISO 5211 and NAMUR standard mounting for easy integration
Compact structure reduces space requirement and simplifies installation
Low maintenance design with long service life
Improved operational efficiency and reduced downtime
Why Choose Fleyenda Valve Manufacturing
Product Stability
We use reinforced structures and precision sealing to ensure consistent performance under pressure and temperature changes.
Conpany&Product Certification
We have CE, RoHS, ISO, SIL, TUV, and IP68 waterproof certifications covering safety, quality, and environmental standards.
Projects Experience
Cooperated over 40 countries, we have experience in oil & gas, energy, water, chemicals, food & beverage, and automation.
Customization Capability
With 20 years experience, we turn complex working conditions into precise valve solutions with high speed and accuracy.
Aftersales Support
•We have technical team provides real-time video support to help customers resolve on-site issues quickly.
Customer Cases
Trusted by Shell plc, Petronas, Chevron, TotalEnergies, and Dupont in projects across 40+ countries.
Our Product Actual Export Pictures
FAQs That 80% Users Interest
1.What kinds of customized services can Fleyenda provide?
Private Labeling, Material Selection, dimensions customized, Actuator Options, etc. We also offer fittings and piping for optional.
Fleyenda is committed to providing you with a one-stop service.
2.How does Fleyenda Valve control the products quality?
We have the IPQC and QC process. We regularly do pressure testing, leakage testing, material analysis, and performance testing. Fleyanda Valve holds ISO 9001, CE, and other certifications.
Fleyedna focuses on upgrading production facilities, testing facilities and focuses on innovation to provide customers with high-quality products in the industry.
3. Can you help us to choose the right products?
Yes, We can help you choose the right valves for your needs. To do so, we would need some specific information from you.
-What is the application or industry which the valves will be used (e.g., oil and gas, water treatment, chemical processing)?
-What is the fluid or gas that will be flowing through the valves?
-What is the working pressure and temperature range for the valves?
And so on.
4.How long does it take you to prepare the goods?
We have a large number of products in stock and can be ready within 7 days. Customized products require 30 days of lead time.
