Intelligent Multi-Turn Electric Globe Valve | FLE-QH-FGV
Intelligent Multi-Turn Electric Globe Valve | FLE-QH-FGV
Lug type motorized round port knife gate valves provide tight shut-off and use an electric actuator for precise, reliable remote control. They are widely used in wastewater treatment, mining, chemical processing, and power generation applications.
Technical Specifications
| Electric Rotary Actuator | |
| FLE-Z20 Rotary Actuator with Globe Valve |
Ordinary ON-OFF Type |
|
Ordinary Adjustable Type |
|
|
Adjusting Switch Type |
|
| Intelligent Type
AC380V AC220V,Special Voltage Can be Customized |
|
| Power Supply | Conventional: Three-phase, AC380V (50 Hz) |
| Special: Three phase, AC660V, AC440V, and AC415V (50Hz and 60Hz) | |
| Special: Simplex, AC220V, AC110V ( 50Hz and 60Hz) | |
| Special: Direct, DC12V, DC24V, and DC48V | |
| Basic Error Limit | ≤1% |
| Protection Class | IP65、IP67, IP68 |
| Explosion-proof Grade | ExdII BT4、ExdII CT4 |
| Motor Working System | Standard Long-term Motor, F-class Insulation |
| Valve Body | |
| Size Range | DN50 – DN1000 |
| Pressure Rating | PN1.0Mpa~PN6Mpa |
| Temperature | -30 to 400℃ |
| Body Material | Cast Iron |
| Stem Material | Cast Iron |
| Sealing | PDEM: -10℃ ~120℃ / PTFE: -30℃ ~180℃ |
| Connection Type | Wafer, Flanged Type |
| Standard | GB/ANSI/JIS/DIN |
| Application Medium | Water, Gas, Oil, Powder, Steam, |
| Applications | Chemical, Water Treatment, Pulp & Paper, Mining, Boiler, etc |
| Boiler, etc | ||||||
| Actuator Model | Standard Time/Torque | Optional Time/Torque | Rotation Angle Range | Actuator Weight | Power Supply | Optional Control Circuit |
|---|---|---|---|---|---|---|
| FLE-105 | 25S/50Nm | 4S/20Nm 10S/30Nm |
0-90° Adjustable | 2.2kg | DC24V AC24V AC110V AC220V AC380V |
A type B type C type D type E type F type |
| FLE-110 | 25S/100Nm | 15S/50Nm | 5.1kg | |||
| FLE-116 | 25S/160Nm | 15S/80Nm | 5.1kg | |||
| FLE-120 | 25S/200Nm | 15S/100Nm | 7.5kg | |||
| FLE-140 | 25S/400Nm | 15S/200Nm | 7.5kg | |||
| FLE-160 | 25S/600Nm | 15S/300Nm | 8.1kg | |||
| FLE-1100 | 50S/1000Nm | 25S/500Nm | 12.7kg | |||
| FLE-1200 | 50S/2000Nm | 25S/1000Nm | 12.7kg | |||
| Type | ON/OFF, Regulating, Intelligent | |||||
| Insulation Resistance | 100MΩ/500VDC | |||||
| Dielectric Strength | 1500V AC 1min. | |||||
| Level of Protection | IP67 (IP68 optional) | |||||
| Installed Location | 360° Installation at any Angle | |||||
| Electrical Interface | 2-G1/2 Metal Fitting, the corresponding metal cable joints should be installed according to the selected cables | |||||
| Ambient temperature | -20°C to +60°C | |||||
| Optional Explosion Proof | Ex d II BT4 / CT4 / CT6 Gb | |||||
| Power-loss reset (fail-safe) function | Fail-open, Fail-closed or No-reset (factory-selectable) | |||||
| Optional functions | Overtorque protection, dehumidification heater, passive contact switch, operating handwheel | |||||
Product Benefits & Features
1. Compact Design & Precise Flow Control
2-inch mini unidirectional globe valve with multi-turn electric actuation
Enables accurate throttling and stable flow regulation
Compact structure suitable for space-limited installation environments
Ideal for smart water systems, irrigation and automated fluid control
2. Intelligent Multi-Turn Electric Actuation
Equipped with QH mini intelligent multi-turn electric actuator
Supports ON-OFF, regulating, and intelligent control modes
Compatible with 4–20 mA, 0–10 V and industrial automation signals
Enables remote control and IoT-based monitoring via PLC/DCS systems
3. Stainless Steel Body & Reliable Sealing
SS304 stainless steel valve body with strong corrosion resistance
EPDM / PTFE sealing ensures stable sealing and long service life
Suitable for water, chemical, irrigation and outdoor environments
Reliable performance under continuous operation conditions
4. Easy Installation & Low Maintenance
Lightweight and compact design for easy installation in limited space
Simple internal structure reduces maintenance complexity
Quick response with stable opening and closing performance
Long service life with reduced operating and maintenance cost
Why Choose Fleyenda Valve Manufacturing
Product Stability
We use reinforced structures and precision sealing to ensure consistent performance under pressure and temperature changes.
Conpany&Product Certification
We have CE, RoHS, ISO, SIL, TUV, and IP68 waterproof certifications covering safety, quality, and environmental standards.
Projects Experience
Cooperated over 40 countries, we have experience in oil & gas, energy, water, chemicals, food & beverage, and automation.
Customization Capability
With 20 years experience, we turn complex working conditions into precise valve solutions with high speed and accuracy.
Aftersales Support
•We have technical team provides real-time video support to help customers resolve on-site issues quickly.
Customer Cases
Trusted by Shell plc, Petronas, Chevron, TotalEnergies, and Dupont in projects across 40+ countries.
Our Product Actual Export Pictures
FAQs That 80% Users Interest
1.What kinds of customized services can Fleyenda provide?
Private Labeling, Material Selection, dimensions customized, Actuator Options, etc. We also offer fittings and piping for optional.
Fleyenda is committed to providing you with a one-stop service.
2.How does Fleyenda Valve control the products quality?
We have the IPQC and QC process. We regularly do pressure testing, leakage testing, material analysis, and performance testing. Fleyanda Valve holds ISO 9001, CE, and other certifications.
Fleyedna focuses on upgrading production facilities, testing facilities and focuses on innovation to provide customers with high-quality products in the industry.
3. Can you help us to choose the right products?
Yes, We can help you choose the right valves for your needs. To do so, we would need some specific information from you.
-What is the application or industry which the valves will be used (e.g., oil and gas, water treatment, chemical processing)?
-What is the fluid or gas that will be flowing through the valves?
-What is the working pressure and temperature range for the valves?
And so on.
4.How long does it take you to prepare the goods?
We have a large number of products in stock and can be ready within 7 days. Customized products require 30 days of lead time.
